HOBBY LINE

SC-1201MG+

25.0 kg/cm |0.16 s/60° |6.0V

Coreless

Line

Application

Servo Size

Operating Voltage

Speed

Torque

Amplifier Type

Motor Type

Case Type

Protection

Dimensions (L x W x H)

Weight

Gear Type

LineHOBBY LINE

ApplicationCAR

Servo SizeStandard

Operating Voltage4.8V-6.0V

Speed0.16 s/60°

Torque25.0 kg/cm

Amplifier TypeDigital Controller

Motor TypeCoreless

Case TypeComposite

ProtectionDust Resistant

Dimensions40.7 x 20.0 x 41.0 mm

Weight69 g

Gear TypeHeavy-Duty Metal

Quick Look: SC-1201MG+ Basher Edition

Meet the SC-1201MG+ – a strong, affordable servo designed for bashers and RTR upgrades.

Andy explains how it delivers 25 kg/cm of torque and added durability at a competitive price.

HOBBY LINE

Simple, reliable, and budget-friendly - the Hobby Line is made for enthusiasts who want trusted Team Savox performance without overcomplicating their build. Whether you're upgrading a ready-to-run vehicle or assembling your first kit, these servos offer solid function at an accessible price.

Equipped with features like metal gears and smooth control response, Hobby Line servos are ideal for casual drivers, beginners, and weekend bashers. It's all about getting you driving with confidence – no stress, no fuss.

Size

Full specification

Line

Application

Servo Size

Operating Voltage

Speed @4.8V

Torque @4.8V

Speed @6.0V

Torque @6.0V

Amplifier Type

Motor Type

Case Type

Protection

Dimensions (L x W x H)

Weight

Gear Type

Compability

PCB Board

Horn Gear Spline

LineHOBBY LINE

ApplicationCAR

Servo SizeStandard

Operating Voltage4.8V-6.0V

Speed @4.8V0.19 s/60°

Torque @4.8V20.0 kg/cm

Speed @6.0V0.16 s/60°

Torque @6.0V25.0 kg/cm

Amplifier TypeDigital Controller

Motor TypeCoreless

Case TypeComposite

ProtectionDust Resistant

Dimensions40.7 x 20.0 x 41.0 mm

Weight69 g

Gear TypeHeavy-Duty Metal

CompabilitySanwa SSR

PCB Board12-bit

Horn Gear Spline25T(Φ6)

Rotating Direction

Max Travel

Operating Travel

Neutral Position

Bearing

Potentiometer

Cable Diameter

Cable Length

Connector

Stall Current @4.8V

Operating Current @4.8V

Stall Current @6.0V

Operating Current @6.0V

Idle Current

Dead Band Width

Frequency Range

Control System

Operating Temperature

Rotating DirectionCounterclockwise (when 1500→2000 μsec)

Max Travel~164° (when 800→2200 μsec)

Operating Travel120° (when 1000→2000 μsec)

Neutral Position1500 μsec

Bearing2x Ball Bearings

PotentiometerVR

Cable Diameter22 AWG

Cable Length300 ±5 mm

ConnectorJR Connector

Stall Current @4.8V8000 mA

Operating Current @4.8V300 mA

Stall Current @6.0V10000 mA

Operating Current @6.0V350 mA

Idle Current5 mA

Dead Band Width3-5 μsec

Frequency Range50-360 Hz

Control SystemPulse width modification

Operating Temperature-10°C to 50°C
