BLACK EDITION
HV

SB-2265MG+

17.0 kg/cm |0.07 s/60° |8.4V

Original Brushless

Line
Application
Servo Size
Operating Voltage
Speed
Torque
Amplifier Type
Motor Type
Case Type
Protection
Dimensions (L x W x H)
Weight
Gear Type
LineBLACK EDITION
ApplicationCAR / AIRPLANE
Servo SizeLow Profile
Operating Voltage6.0V-8.4V
Speed0.07 s/60°
Torque17.0 kg/cm
Amplifier TypeDigital Controller
Motor TypeOriginal Brushless
Case TypeHybrid (Aluminum/Composite)
ProtectionWater Resistant
Dimensions40.8 x 20.2 x 25.4 mm
Weight50 g
Gear TypeHeavy-Duty Metal

Discover the SB-2265MG+ in Detail

Curious about what makes the SB-2265MG+ stand out? In this video, Andy from Team Savox walks you through all the key features of this advanced low-profile brushless servo. From its high-voltage capability to its upgraded wiring and blazing-fast response, you’ll get an inside look at why it’s a top choice for competitive 1/10 on-road racers.

Designed as a high-performance evolution of the 2263, the SB-2265MG+ offers more torque, a longer 20cm cable, and full compatibility with Sanwa SSR for ultra-fast signal response. Whether you’re building a new chassis or simply want more power in a compact servo, this is the one to watch.

BLACK EDITION

A sleek, all-black design applied to our most trusted servo platforms. Black Edition models take the proven internals from other Team Savox lines and wrap them in a clean, stealthy finish.

Perfect for clean builds, custom chassis, or anyone who wants standout performance with low-profile styling. Same power - just darker.

Size

Full specification

Line
Application
Servo Size
Operating Voltage
Speed @6.0V
Torque @6.0V
Speed @7.4V
Torque @7.4V
Speed @8.4V
Torque @8.4V
Amplifier Type
Motor Type
Case Type
Protection
Dimensions (L x W x H)
Weight
Gear Type
Compability
PCB Board
Horn Gear Spline
LineBLACK EDITION
ApplicationCAR / AIRPLANE
Servo SizeLow Profile
Operating Voltage6.0V-8.4V
Speed @6.0V0.1 s/60°
Torque @6.0V10.0 kg/cm
Speed @7.4V0.08 s/60°
Torque @7.4V13.0 kg/cm
Speed @8.4V0.07 s/60°
Torque @8.4V17.0 kg/cm
Amplifier TypeDigital Controller
Motor TypeOriginal Brushless
Case TypeHybrid (Aluminum/Composite)
ProtectionWater Resistant
Dimensions40.8 x 20.2 x 25.4 mm
Weight50 g
Gear TypeHeavy-Duty Metal
CompabilitySanwa SUR, SSR; Futaba UR, SR
PCB Board32-bit
Horn Gear Spline25T(Φ6)
Rotating Direction
Max Travel
Operating Travel
Neutral Position
Bearing
Potentiometer
Cable Diameter
Cable Length
Connector
Stall Current @6.0V
Operating Current @6.0V
Stall Current @7.4V
Operating Current @7.4V
Stall Current @8.4V
Operating Current @8.4V
Idle Current
Dead Band Width
Frequency Range
Control System
Operating Temperature
Rotating DirectionCounterclockwise (when 1000→2000 μsec)
Max Travel~130° (when 900→2100 μsec)
Operating Travel90° (when 1000→2000 μsec)
Neutral Position1500 μsec
Bearing2x Ball Bearings
PotentiometerVR
Cable Diameter22 AWG
Cable Length200 ±5 mm
ConnectorJR Connector
Stall Current @6.0V5000 mA
Operating Current @6.0V200 mA
Stall Current @7.4V6000 mA
Operating Current @7.4V220 mA
Stall Current @8.4V7000 mA
Operating Current @8.4V250 mA
Idle Current5 mA
Dead Band Width3-5 μsec
Frequency Range50-360 Hz
Control SystemPulse width modification
Operating Temperature-10°C to 50°C
